Board-to-board receptacle, 2.00 mm pitch
The 55510-116TR is the 16-position dual-row member of Amphenol ICC (FCI)'s Minitek 2.00 mm receptacle line, a board-to-board style with push-pull fastening.
55510-116TR Amphenol ICC (FCI) Minitek 2.00mm Receptacle
MPN55510-116TR
Obsolete
Amphenol ICC (FCI) Minitek® 2.00mm receptacle, order code 55510-116TR, 16 positions, dual row, 2.00 mm pitch, 2 A, 200 V, gold-plated mating contacts, surface-mount, solder termination.
$1.6896Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Female Socket |
| Mounting | Surface Mount |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 200V |
| Current rating | 2A |
| Operating temperature | -55°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.177\" (4.50mm) |
| Insulation material | Plastic |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Termination | Solder |
| Applications | General Purpose, Industrial, Medical |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 16 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin-Lead |
| Contact finish - mating | Gold |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
How do I get current pricing and availability for 55510-116TR?
Availability is confirmed at RFQ through independent surplus channels. Submit a quote request for lot-specific quantities.
What compliance documentation does Amphenol ICC (FCI) provide for 55510-116TR (RoHS, REACH, UL, IEC)?
RoHS and REACH compliance status is not confirmed in available records.
