Amphenol ICC (FCI) Minitek® 2.00mm series, 57102-F06-07ULF, 14-position dual-row unshrouded header, through-hole solder termination, 2A per contact, gold flash on mating surface, push-pull fastening, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.059\" (1.50mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 14 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.098\" (2.50mm) |
| Overall contact length | 0.315\" (8.00mm) |
| Contact finish - mating | Gold |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | Flash |
The 57102-F06-07ULF: The header mates with a matching Minitek 2.00mm receptacle (sold separately) via a push-pull fastening interface. Gold flash on the mating contact surface provides reliable signal-level connectivity for moderate mating cycles.
The unshrouded design keeps the z-height low (0.315" overall contact length) and allows board-edge routing without a shroud keep-out.
Yes, 57102-F06-07ULF is RoHS compliant per the manufacturer's listing.
The header is rated 2 A (AC/DC) per contact. Derate above ambient temperature per the Minitek 2.00mm derating curve.
