57202-G52-15LF — Amphenol product photo
Amphenol

57202-G52-15LF Amphenol ICC (FCI) Minitek® 2.00mm Header

MPN57202-G52-15LF
Active

Amphenol ICC (FCI) Minitek® 2.00mm series, board-to-board header, 30 positions, 2 rows, unshrouded, surface mount, gold GXT™ plated male pins, rated 2 A per contact at 200 V, UL94 V-0.

$3.5800Ref. price · indicative, final on quote
57202-G52-15LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

57202-G52-15LF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderMale Pin
Mounting typeSurface Mount
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorBlack
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions30
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact finish - matingGold, GXT™
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - post78.7µin (2.00µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

30-Position SMT Header for Board-to-Board Stacking

Surface-mount termination means the header reflows alongside other SMT components, saving a wave-solder pass.

Gold GXT™ Plating for Repeated Mating

The mating surface carries 30.0 µinch (0.76 µm) gold over nickel, designated GXT™ — a hard gold alloy rated for 500 mating cycles minimum. In a test fixture or modular instrument where boards are swapped weekly, that is decades of reliable contact without fretting corrosion. The solder tails are tin-plated (78.7 µinch / 2.00 µm), which wets well during reflow and is compatible with standard SAC305 solder paste.

Unshrouded Design and Mating Requirements

This header is unshrouded — no plastic wall surrounds the pins.

The base product number 57202 covers the Minitek® 2.00mm dual-row header family. Available in bulk packaging.

Frequently asked questions

Where can I buy 57202-G52-15LF and how do I get a price?

The 57202-G52-15LF is an active part from Amphenol ICC (FCI). We source it through independent distribution channels.

What is the pitch of 57202-G52-15LF?

The mating pitch is 0.079" (2.00 mm), and the row spacing is also 0.079" (2.00 mm). This gives a 30-position dual-row footprint that is 2.00 mm × 15 pins per row.

Is 57202-G52-15LF surface mount?

Yes, the termination is surface mount (SMT). The header is designed for reflow soldering onto PCB pads, with no through-hole holes required.

Is 57202-G52-15LF shrouded or unshrouded?

It is unshrouded — there is no plastic shroud around the pins. The mating receptacle must provide its own alignment and keying.

What is the closest pin-compatible alternative to 57202-G52-15LF in this Pin Headers, Sockets & Housings family?

The base product number 57202 covers the Minitek® 2.00mm dual-row header family; other position counts or plating options may be available under the same base number.
