Amphenol ICC (FCI) Minitek® 2.00mm header, order code 57202-G52-18LF, 36 positions, dual row, 0.079" (2.00mm) pitch, 2A (AC/DC), 200V (AC/DC), gold GXT™ mating contacts, surface-mount, solder termination, unshrouded.
| Parameter | Value |
|---|---|
| Series | Minitek® 2.00mm |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 36 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 57202-G52-18LF is the 36-circuit member of Amphenol ICC (FCI)'s Minitek® 2.00mm board-to-board header line. It carries gold GXT™ mating contacts rated 2A (AC/DC) at 200V (AC/DC) and mounts surface-mount with solder termination. The unshrouded push-pull fastening and 0.079" row spacing suit parallel board stacking where the mating receptacle is keyed by the PCB layout.
The style is Board to Board and the series is Minitek® 2.00mm — a 0.079" pitch, dual-row header family.
