Amphenol ICC (FCI) Minitek® 2.00mm pitch, 12-position, dual-row, right-angle through-hole header, unshrouded male pins, gold GXT™ plating, 2 A AC/DC, 200 V AC/DC, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | Minitek® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.165\" (4.20mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 12 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 58102-G61-06LF: The unshrouded male pins with square contact shape mate with Minitek® receptacle housings or IDC sockets for wire-to-board or board-to-board configurations.
RoHS compliant per the listed compliance data.
The 58102-G61-06LF (12 positions) sits between the 10-position 58102-G61-05LF and the 14-position 58102-G61-07LF in the same right-angle, dual-row, 2.00 mm pitch, gold GXT™ plated family.
Within the same Minitek® series, the 58102-G61-07LF is a 14-position version with identical pitch, plating, and mounting. For a direct 12-position match, no second-source is listed — the 58102-G61-06LF is the only 12-position variant in this right-angle, gold-plated subfamily.
