Amphenol ICC (FCI) Minitek® unshrouded header, order code 58102-G61-10LF, 20 positions, 2.00 mm pitch, dual-row, through hole right angle, male pin, gold GXT™ plating, 2 A, 200 V, UL94 V-0 black thermoplastic, RoHS.
| Parameter | Value |
|---|---|
| Series | Minitek® |
| Gender | Male Pin |
| Mounting type | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.165\" (4.20mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 20 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 58102-G61-10LF: Right-angle through-hole termination means the pins sit perpendicular to the PCB edge, useful for board-to-cable routing where the z-height above the board is tight.
Gold this thick handles quarterly cycling for decades without contact fretting.
Row spacing is also 2.00 mm.
Yes, RoHS compliant per the manufacturer listing.
