Amphenol ICC (FCI) Minitek 2.00mm pitch header, 24 positions, unshrouded male pin, through-hole right-angle, 30µin GXT gold mating finish, 2A rated, UL94 V-0, black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | Minitek® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.165\" (4.20mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 24 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 0.098" (2.50mm) post length gives enough standoff for solder fillet inspection on a standard 1.6mm board. Solder termination is manual or wave-solder compatible – no press-fit tooling needed.
In a mixed-power/signal layout, keep the total current per row under 12A to stay within the UL94 V-0 housing's thermal budget.
The mating pitch is 0.079" (2.00mm) with a matching 0.079" (2.00mm) row spacing – dual-row layout.
The part is listed as RoHS compliant per the manufacturer's specification.
