Amphenol ICC (FCI) Minitek® header, 58102-G61-16LF, 32 positions, 2.00 mm pitch, through-hole right-angle, unshrouded male pins, 2 A, 30 µinch GXT gold mating finish, UL94 V-0 black thermoplastic housing.
| Parameter | Value |
|---|---|
| Series | Minitek® |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Voltage rating | 200V (AC/DC) |
| Current rating | 2A (AC/DC) |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.165\" (4.20mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board or Cable |
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.079\" (2.00mm) |
| Positions | 32 |
| Row spacing - mating | 0.079\" (2.00mm) |
| Contact length - post | 0.098\" (2.50mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.157\" (4.00mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 58102-G61-16LF: The unshrouded design means the mating receptacle slides directly over the pins without a surrounding wall — this saves board space but offers no keying, so the mating connector must be aligned manually during assembly.
The 200 V AC/DC voltage rating covers typical low-voltage signal and control circuits.
This unshrouded header mates with a Minitek 2.00 mm pitch receptacle housing (e.g., 76342 series) loaded with female crimp terminals.
Through-hole, right-angle.
