58102-S61-08LF — Amphenol product photo
Amphenol

58102-S61-08LF Amphenol ICC Minitek® 16-Pin Right-Angle

MPN58102-S61-08LF
Active

Amphenol ICC (FCI) Minitek® series, 58102-S61-08LF, 16-position unshrouded header, 2-row, 2.00mm pitch, right-angle through-hole, gold GXT™ plated male pins, 2A, 200V, UL94 V-0, black thermoplastic, RoHS, active.

$1.8600Ref. price · indicative, final on quote
58102-S61-08LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

58102-S61-08LF Technical Specifications
ParameterValue
SeriesMinitek®
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating200V (AC/DC)
Current rating2A (AC/DC)
Contact materialCopper Alloy
Insulation colorBlack
Insulation height0.165\" (4.20mm)
Insulation materialThermoplastic
Material flammability ratingUL94 V-0
StyleBoard to Board or Cable
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions16
Row spacing - mating0.079\" (2.00mm)
Contact length - post0.098\" (2.50mm)
Contact finish - matingGold, GXT™
Contact length - mating0.157\" (4.00mm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

Board Layout Fit: 2.00mm Pitch, Right-Angle Orientation

The 58102-S61-08LF: This is a 16-position, 2-row unshrouded header on 2.00mm pitch — the footprint matches a 2.00mm grid, so the board layout needs a 0.079" row spacing and a 0.098" post length for the solder tails.

Current and Contact: 2A with Gold GXT™ Plating

The square male pins mate with standard Minitek® crimp receptacles or IDC sockets.

This unshrouded header mates with Minitek® 2.00mm pitch crimp socket housings and IDC receptacles.

Frequently asked questions

Where can I buy 58102-S61-08LF and how is it quoted?

No stock-holding claim; submit an RFQ for your required volume.

What is the pitch and mounting style of 58102-S61-08LF?

The mating pitch is 2.00mm (0.079") with a row spacing of 2.00mm. Mounting style is through-hole, right-angle.
