63453-130LF — Amphenol product photo
Amphenol

63453-130LF Amphenol ICC Minitek 2.00mm 30-Pin Receptacle

MPN63453-130LF
Active

Amphenol ICC (FCI) Minitek 2.00mm series, 30-position dual-row board-to-board receptacle, through-hole solder termination, 2A per contact, 200V rating, gold mating finish, UL94 V-0 black PCT housing.

$1.9174Ref. price · indicative, final on quote
63453-130LF datasheet
StockContact for availability
Lead time3-5 Days wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

63453-130LF Technical Specifications
ParameterValue
SeriesMinitek® 2.00mm
GenderFemale Socket
Mounting typeThrough Hole
Connector typeReceptacle
Fastening typePush-Pull
Voltage rating200V
Current rating2A
Operating temperature-55°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.177\" (4.50mm)
Insulation materialPolycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageTube
TerminationSolder
ApplicationsGeneral Purpose, Industrial, Medical
Contact shapeSquare
Rows2
Pitch0.079\" (2.00mm)
Positions30
Row spacing - mating0.079\" (2.00mm)
Contact finish - postTin
Contact length - post0.098\" (2.50mm)
Contact finish - matingGold
Contact finish thickness - post60.0µin (1.52µm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Board-to-Board Interconnect for Dense PCB Stacks

The 2.00mm pitch (0.079") and 0.079" row spacing set the board footprint and routing density — at 30 circuits the connector occupies roughly 30mm × 8mm of board area, leaving room for trace fan-out between rows.

Current, Voltage, and Contact Plating

The post finish is 60µinch tin (1.52µm), which solders reliably with standard lead-free profiles. The UL94 V-0 rated PCT glass-filled housing (Polycyclohexylenedimethylene Terephthalate) provides flame retardancy for equipment inside an enclosure — a common compliance requirement for medical and industrial builds.

Frequently asked questions

What is the pitch of 63453-130LF?

The mating pitch is 0.079" (2.00mm), with the same 0.079" row spacing. This is the standard Minitek 2.00mm pitch — the board footprint matches all Minitek 2.00mm pin headers.

Is 63453-130LF RoHS compliant?

The part number suffix 'LF' indicates lead-free / RoHS-compliant termination finish. The tin post finish and gold mating finish are RoHS-compatible materials.
