Free-hanging FFC/FPC receptacle with flip lock
The 65801-034LF is the 5-circuit member of Amphenol ICC (FCI)'s Clincher FFC/FPC receptacle line, terminated by soldering the notched cable end into the housing.
Amphenol ICC (FCI) 65801-034LF Clincher FFC/FPC Receptacle
MPN65801-034LF
Active
Amphenol ICC (FCI) Clincher FFC/FPC receptacle, order code 65801-034LF, 5 positions, 0.100" (2.54mm) pitch, 2 A, 500 V, gold or gold GXT mating contacts, free-hanging in-line, solder termination.
$1.9500Ref. price · indicative, final on quote
RoHSRoHS Compliant
SeriesClincher™
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | Clincher™ |
| Mounting | Free Hanging (In-Line) |
| Cable end type | Notched |
| Flat flex type | FFC, FPC |
| Connector (Contact type) | Receptacle |
| Voltage rating | 500V |
| Current rating | 2A |
| Operating temperature | -65°C~105°C |
| Housing color | Blue |
| Actuator color | Beige |
| Contact material | Copper Nickel Alloy |
| Housing material | Thermoplastic |
All specifications
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Package | Tray |
| Features | Solder Retention |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Gold or Gold, GXT™ |
| Locking feature | Flip Lock |
| FFC, FCB thickness | 0.20mm |
| Positions | 5 |
| Contact finish thickness | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Will 65801-034LF drop into a panel that was specified around 65801-033LF without rewiring?
The 65801-034LF has 5 positions versus 4 on the 65801-033LF; the pitch, mounting style, and contact finish are identical, so the footprint and mating half are shared, but the extra circuit requires a corresponding change in the cable assembly and mating connector.
