FFC header with ZIF flip-lock
The 66226-015LF is the 15-position member of Amphenol ICC's Clincher FFC header line, using a zero-insertion-force flip-lock actuator for the FFC cable end. Rated 2 A per contact at 500 V, the tin-plated contacts accept 0.30 mm FFC thickness and are rated for 100 mating cycles.
Pitch and FFC fit
The 0.100" (2.54mm) pitch and 0.30 mm FFC thickness are fixed across the Clincher series — the 15-position 66226-015LF matches the same board footprint as other position counts in the family. The ZIF flip-lock and backlock hold the tapered FFC end without insertion force, and the solder retention features keep the header in place during wave soldering.
