Amphenol ICC (FCI) Clincher FFC header, order code 66226-018LF, 18 positions, 0.100" (2.54mm) pitch, 2 A, 500 V, tin-plated contacts, free hanging, ZIF actuation, solder termination.
| Parameter | Value |
|---|---|
| Series | Clincher™ |
| Mounting | Free Hanging (In-Line) |
| Cable end type | Straight |
| Flat flex type | FFC |
| Connector (Contact type) | Header |
| Voltage rating | 500V |
| Current rating | 2A |
| Operating temperature | -65°C~105°C |
| Housing color | Blue |
| Actuator color | Black |
| Contact material | Copper Nickel Alloy |
| Housing material | Thermoplastic |
| Parameter | Value |
|---|---|
| Material flammability rating | UL94 V-0 |
| Pitch | 0.100\" (2.54mm) |
| Package | Tray |
| Features | Solder Retention, Zero Insertion Force (ZIF) |
| Termination | Solder |
| Mating cycles | 100 |
| Contact finish | Tin |
| Locking feature | Flip Lock, Backlock |
| FFC, FCB thickness | 0.30mm |
| Positions | 18 |
| Contact finish thickness | 100.0µin (2.54µm) |
The 66226-018LF is the 18-circuit member of Amphenol ICC (FCI)'s Clincher FFC header line, a free-hanging connector with zero insertion force (ZIF) actuation and a flip-lock backlock. Rated 2 A per contact at 500 V, it accepts 0.30 mm FFC and carries tin-plated contacts on a 0.100" (2.54mm) pitch.
The 66226-018LF is an 18-position header on a 0.100" (2.54mm) pitch.
The housing is rated UL94 V-0. RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) upon request.
