Amphenol ICC (FCI) Quickie™ series, 66506-043LF, 16-position dual-row shrouded header, 0.100" (2.54mm) pitch, through-hole solder termination, 30µinch gold-plated male pins, black glass-filled polyester housing, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Quickie™ |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.365\" (9.27mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tray |
| Parameter | Value |
|---|---|
| Features | Keying Slot |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 16 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.105\" (2.67mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
A keying slot on the housing prevents mismating with non-keyed receptacles, which is useful when multiple similar headers share a board.
For applications with moderate vibration, the keying slot and 4-wall shroud provide enough alignment to keep the contacts stable.
66506-043LF is an active-production part. Submit a quote request for current pricing and delivery.
Yes, the housing includes a keying slot, which prevents mismating with non-keyed receptacles. This is a standard feature on Quickie™ shrouded headers.
