Amphenol ICC (FCI) Dubox™ / BergCon® PV™ 12-position single-row female socket header, 0.100" (2.54mm) pitch, through-hole solder termination, 30µin gold mating finish, rated 1250V, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | Dubox™, BergCon® PV™ |
| Type | Female Socket |
| Mounting | Through Hole |
| Connector type | Receptacle |
| Fastening type | Push-Pull |
| Voltage rating | 1250V |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Brass |
| Insulation color | Black |
| Insulation height | 0.325\" (8.25mm) |
| Insulation material | Polyester, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Board |
| Package | Tube |
| Termination | Solder |
| Applications | Automotive, General Purpose, Industrial, Medical, Telecommunications |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 12 |
| Contact finish - post | Tin |
| Contact length - post | 0.142\" (3.60mm) |
| Contact finish - mating | Gold |
| Contact finish thickness - post | 100.0µin (2.54µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 66951-012LF: The single row keeps the board width narrow; the 0.142" (3.60mm) solder tail length gives a solid through-hole joint on standard 1.6mm PCBs.
Voltage rating is 1250V — unusually high for a 2.54mm pitch signal connector; this suits it for power distribution or high-voltage signal paths inside equipment. Housing is glass-filled polyester, UL94 V-0 rated — required for equipment inside a UL-listed enclosure.
This is a female socket header — it mates with a 0.100" pitch, 12-position, single-row male pin header (BergStik® or equivalent) with square pins. Confirm the pin length and stack height against your board spacing.
