Amphenol FCI BERGSTIK II header, order code 67996-162HLF, 62 positions, dual row, 0.100" (2.54mm) pitch, 3A per contact, gold-plated mating contacts 30.0µin (0.76µm), through-hole, solder termination, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 62 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 67996-162HLF is the 62-position member of Amphenol FCI's BERGSTIK II header line, a dual-row unshrouded male pin header on 0.100" pitch. Rated 3A per contact with gold or GXT plating at 30.0µin thickness on the mating surface, it operates from -65°C to 125°C and carries a UL94 V-0 flammability rating.
Sourced and quoted to order against your BOM quantity through independent distribution. Availability and current pricing are confirmed at quote time — no live stock count or lead-time figure is published on this listing; submit an RFQ to get a quote for your required quantity and target date.
