Amphenol ICC (FCI) BERGSTIK® II, 67996-272HLF, 72-position, dual-row, unshrouded pin header, 0.100" (2.54mm) pitch, through-hole solder termination, 3A per contact, 15.0µin gold plating, UL94 V-0, -65°C to 125°C.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 67996-272HLF: The through-hole solder termination and 0.095" (2.41mm) post length suit it for standard PCB thicknesses; the 0.230" (5.84mm) mating pin length provides reliable contact wipe in the mating receptacle.
For comparison, the sibling 67996-172HLF carries 30.0µin gold plating — double the thickness, which extends mating cycle life further in high-wear or corrosive environments.
0.100" (2.54mm) pitch, dual rows, 72 positions total, all loaded.
Within the same BERGSTIK® II series, the 67996-172HLF shares the same 72-position count and pitch but uses 30.0µin gold plating — a drop-in replacement if thicker plating is acceptable. The 4-position 67996-204HLF is not a functional substitute.
