Amphenol ICC (FCI) BERGSTIK® II, 67996-436HLF, unshrouded through-hole header, 36 circuits, dual-row 0.100" (2.54 mm) pitch, tin-plated contacts, rated 3 A per contact, -65°C to 125°C, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C~125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 36 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.425\" (10.80mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 67996-436HLF: Rated 3 A per contact with tin-on-tin mating surfaces, the current ceiling suits signal-level loads — logic lines, sensor inputs, low-power I/O — where the contact resistance of tin (stable below 100°C) is acceptable.
The square pins accept standard crimp receptacles or IDC sockets designed for 0.025" square posts.
It is RoHS compliant.
All positions are loaded.
It is an unshrouded header with a push-pull fastening type. The mating receptacle provides the retention — no integral locking latch on the header itself.
