Amphenol ICC (FCI) BERGSTIK® II unshrouded header, 10 positions, 2 rows, 0.100" (2.54 mm) pitch, male square pins, through-hole solder termination, tin-plated contacts, black UL94 V-0 housing, rated 3 A per contact.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Tube |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.450\" (11.43mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 67997-410HTLF: The 0.230" mating pin length gives enough reach for a typical box-header or IDC receptacle, and the 0.120" solder tail fits a 0.062" board with room for a wave-solder fillet.
Through-hole solder termination — the 0.120" post length fits standard 1.6 mm (0.062") PCBs with enough protrusion for a reliable solder joint. No board locks or alignment pegs: the pins themselves provide the alignment during soldering.
Yes, the BERGSTIK II series uses a RoHS-compliant material set. The tin plating and UL94 V-0 black housing are standard for the series.
