Amphenol ICC (FCI) BERGSTIK® II, 68001-106HLF, unshrouded vertical header, 6 positions, 0.100" (2.54 mm) pitch, through-hole solder termination, 3 A per contact, 30 µinch gold mating finish, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.450\" (11.43mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 68001-106HLF: Rated 3 A per contact, with the current ceiling limited by the contact cross-section and housing material — fine for signal-level loads and moderate power distribution on a 6-circuit bus.
RoHS compliant.
Physically yes — same 0.100" pitch, same single-row layout. The 6-position header will fit the 8-position footprint with the outer two positions left empty. Confirm the mating half position count matches your circuit count.
RoHS compliant per the lifecycle record.
