Amphenol ICC (FCI) BERGSTIK® II header, order code 68015-134HLF, 34 positions, single row, 0.100" (2.54 mm) pitch, 3 A per contact, gold-plated square pins, through-hole right-angle, solder termination, push-pull fastening, UL94 V-0.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.095\" (2.41mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Parameter | Value |
|---|---|
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 34 |
| Contact length - post | 0.090\" (2.29mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 68015-134HLF is the 34-position member of Amphenol ICC (FCI)'s BERGSTIK II unshrouded header line, terminated through-hole right-angle with solder tails 0.090" (2.29 mm) long. Gold-plated square pins on a 0.100" (2.54 mm) pitch carry 3 A per contact; the black UL94 V-0 housing mates with any standard 0.025" square-post receptacle.
The header carries a UL94 V-0 flammability rating on the insulation material. RoHS and REACH compliance documentation is provided by Amphenol ICC (FCI) per standard industry practice.
