13-Position Single-Row BERGSTIK II Header – 0.100" Pitch, Right-Angle
The 68016-413: Tin is cost-effective for low-cycle applications (under 50 mates) in clean, indoor environments.
Unshrouded Push-Pull Interface – No Polarization, No Latch
The header is unshrouded and uses push-pull fastening. There is no shroud to guide the mating socket, so alignment depends on the socket housing's own lead-in chamfer. No locking latch means the mated pair can separate under vibration or cable snag — this is a board-to-board or wire-to-board interconnect for low-vibration environments like test equipment or consumer electronics.
Obsolete – Sourced Through Independent Channels
Amphenol ICC (FCI) has marked the 68016-413 as Obsolete. For new designs, consider a current-production 0.100" single-row header from the same pitch family — verify the mating half and board layout.
The connector is bulk-packaged — no tape-and-reel, so hand-insertion or tube-fed assembly is expected.
