68020-120HLF — Amphenol product photo
Amphenol

68020-120HLF Amphenol ICC (FCI) BERGSTIK® II 20-Pin

MPN68020-120HLF
Active

Amphenol ICC (FCI) BERGSTIK® II, 68020-120HLF, 20-position unshrouded male header, 0.100" (2.54 mm) pitch, right-angle through-hole, 3 A per contact, 30 µinch gold mating finish, UL94 V-0.

$1.4300Ref. price · indicative, final on quote
68020-120HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68020-120HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Current rating3A per Contact
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions20
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.095\" (2.41mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

20-Position Right-Angle Header — Board-to-Board Fit

The 68020-120HLF: The right-angle orientation and 0.095" (2.41 mm) solder post length place the pin tips close to the board surface, which keeps the z-height low in compact enclosures.

3 A per Contact — Current and Temperature Range

Each phosphor bronze contact is rated 3 A continuous at the listed temperature.

The closest peer in the same BERGSTIK® II series is the 68021-116HLF — identical in pitch (0.100"), plating (30 µinch gold), current rating (3 A), and right-angle through-hole mounting. The difference is circuit count: 20 positions on the 68020-120HLF versus 16 positions on the 68021-116HLF.

Frequently asked questions

Is 68020-120HLF RoHS compliant?

Yes, the manufacturer lists it as RoHS compliant.

What is the closest functional equivalent to 68020-120HLF?

The 68021-116HLF is the closest sibling — same series, pitch, plating, and current rating, but with 16 positions instead of 20. For a 20-position requirement, this is the correct order code.

Where can I buy 68020-120HLF?

Availability and pricing confirmed at quote time.
