50-position right-angle BergStik II
The 68020-450HLF is the 50-position member of the BergStik II unshrouded header line from Amphenol ICC (FCI), arranged in two rows at the standard 0.100" pitch.
68020-450HLF Amphenol ICC (FCI) BergStik II Header, 50 Pos
MPN68020-450HLF
Active
Amphenol ICC (FCI) BergStik II header, order code 68020-450HLF, 50 positions, dual row, 0.100" (2.54mm) pitch, 3 A per contact, tin-plated mating contacts, through-hole right-angle, solder termination.
$1.8948Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A per Contact |
| Operating temperature | -65°C ~ 125°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.190\" (4.83mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
All specifications
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 50 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.095\" (2.41mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Product details
Frequently asked questions
What is the closest pin-compatible alternative to the 68020-450HLF in the BergStik II series?
The BergStik II series includes many 0.100" pitch dual-row headers with the same footprint. The closest parametric neighbour would share the same pitch, row spacing, and tin-plated contacts but differ in position count — for example, a 40-position or 60-position member of the same series. No single pin-compatible alternative is listed as a direct cross-reference.
