2.54mm Pitch, 12 Positions, Right-Angle Exit
Mating pin length is 0.230" (5.84mm); the post length below the insulator is 0.195" (4.95mm). The insulator stands 0.190" (4.83mm) off the board. These dimensions set the z-height budget for the mating receptacle and the through-hole solder tail length. All 12 positions are loaded.
The closest peer in the same BERGSTIK® II series is 68021-210HLF: identical pitch, plating, right-angle orientation, and UL94 V-0 rating, but with 10 positions instead of 12. If the BOM calls for 12 circuits, this is the correct count; the 10-position part is a drop-in for a 10-circuit layout but leaves two positions unpopulated.
