68405-106HLF — Amphenol product photo

68405-106HLF BERGSTIK II Header, 6 Pos, 0.100" Pitch, 5A

MPN68405-106HLF
Active

Amphenol BERGSTIK® II, 68405-106HLF, 6-position unshrouded header, 0.100" (2.54mm) pitch, 2 rows, 5A, right-angle through-hole, gold-plated phosphor bronze pins.

$0.3171Ref. price · indicative, final on quote
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

68405-106HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions6
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.095\" (2.41mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The Amphenol 68405-106HLF is a 6-position, dual-row unshrouded header from the BERGSTIK® II series, built for board-to-board interconnect on a 0.100" (2.54mm) pitch. Each square male pin carries a 5A current rating and is plated with 30.0µin gold or GXT™ on the mating surface — the gold thickness supports repeated mating cycles in field-service or test-fixture applications without the contact degradation you'd see with tin.

The 0.100" pitch and 0.100" row spacing match the standard through-hole footprint. The 0.230" mating pin length and 0.095" post length suit common receptacles and single-board soldering.

Frequently asked questions

What is the pitch of 68405-106HLF?

Buyers need to verify pin spacing matches their PCB design.

Where can I buy 68405-106HLF in stock?

Sourcing buyers need immediate availability to avoid production delays.

What is the datasheet for 68405-106HLF?

Design engineers require full electrical and mechanical specifications for validation.

Is 68405-106HLF RoHS compliant?

Compliance with environmental regulations is mandatory for many projects.

What is the price of 68405-106HLF?

Buyers compare costs across distributors for budget planning.

What mating connector works with 68405-106HLF?

Ensures proper connectivity in board-to-board applications.
