68438-472HLF — Amphenol product photo

Amphenol BERGSTIK II 68438-472HLF Header, 72 Pos, 5 A

MPN68438-472HLF
Obsolete

Amphenol BERGSTIK II, 0.100" (2.54 mm) pitch, 72 positions (2×36), unshrouded header, through-hole, tin-plated contacts, 5 A, 110 V, UL94 V-0, black insulation.

$8.0352Ref. price · indicative, final on quote
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.

Specifications

68438-472HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions72
Row spacing - mating0.100\" (2.54mm)
Contact finish - postTin
Contact length - post0.225\" (5.72mm)
Overall contact length0.555\" (14.10mm)
Contact finish - matingTin
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

The Amphenol BERGSTIK® II 68438-472HLF is a 72-position (2×36), 0.100-inch (2.54 mm) pitch unshrouded male pin header for board-to-board signal interconnect. The UL94 V-0 black insulation and push-pull fastening suit it for internal board stacking in industrial control, telecom, and test equipment where the open pin field allows direct mating with a standard 0.100-inch receptacle.

The 0.100-inch pitch and 72-position count are common enough that a parametric search across the BERGSTIK II or similar unshrouded header families may yield a form-fit-function alternative, but no official cross-reference is available here.

The 0.100-inch pitch and 0.100-inch row spacing are the industry-standard 2.54 mm grid — the board footprint is a 2×36 array of 0.040-inch plated-through holes on that grid.

Frequently asked questions

Where can I buy 68438-472HLF available via RFQ confirmation today?

The 68438-472HLF is obsolete and no longer in regular production. It is sourced to order against an RFQ through independent distribution and surplus channels — current availability and pricing are confirmed at quote time. Contact the storefront with your BOM quantity for a same-day quote.

Is 68438-472HLF obsolete?

Yes, the 68438-472HLF carries an Obsolete lifecycle status per the manufacturer. No official replacement or successor order code has been published.

What is the pin pitch of 68438-472HLF?

The mating pitch is 0.100 inch (2.54 mm), with the same 0.100 inch row spacing — a standard 2.54 mm grid footprint.
