At this thickness the contact supports 500+ mating cycles without exposing the nickel underplate — a practical fit for field-service equipment where the board is swapped quarterly over a 10–15 year service life. Gold plating also suppresses fretting corrosion in low-current signal paths (below 10 mA), where tin contacts can form an insulating oxide layer under vibration. For purely power circuits at 3 A, the gold layer is a margin-of-safety choice rather than a necessity.
68481-172HLF BergStik II Header – 72-Pin, 0.100" Pitch, Gold
MPN68481-172HLF
Active
Amphenol ICC (FCI) BergStik® II, 72-position dual-row unshrouded header, 0.100" (2.54 mm) pitch, through-hole solder termination, 30.0 µinch gold-plated mating contacts, rated 3 A per contact, UL94 V-0 black housing.
$5.1052Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
All specifications
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.095\" (2.41mm) |
| Overall contact length | 0.480\" (12.19mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.285\" (7.24mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Where can I buy 68481-172HLF and how do I get a price?
No stock-holding claim is made; availability is verified per inquiry.
Is 68481-172HLF compatible with BergStik II receptacles?
Confirm the receptacle's position count matches 72 positions.
