68488-418HLF — Amphenol product photo
Amphenol

68488-418HLF Amphenol ICC (FCI) BergStik II Header, 18 Pos

MPN68488-418HLF
Active

Amphenol ICC (FCI) BergStik II header, order code 68488-418HLF, 18 positions, single row, 0.100" (2.54 mm) pitch, 3 A, tin-plated mating contacts, through-hole right-angle, solder termination.

$0.3783Ref. price · indicative, final on quote
68488-418HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68488-418HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C ~ 125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.095\" (2.41mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions18
Contact finish - postTin
Contact length - post0.180\" (4.57mm)
Contact finish - matingTin
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

BergStik II unshrouded header, 18 positions

The 68488-418HLF is the 18-circuit member of Amphenol ICC (FCI)'s BergStik II unshrouded male pin header line. It carries tin-plated contacts rated 3 A and mounts through-hole right-angle with solder termination.

Frequently asked questions

Does 68488-418HLF meet RoHS requirements?

The 68488-418HLF is RoHS compliant as supplied by Amphenol ICC (FCI).
