Amphenol ICC (FCI) BERGSTIK® II, 68491-120H, 20-position dual-row unshrouded header, 0.100" (2.54mm) pitch, through-hole solder termination, 30µin gold or GXT™ mating surface, rated 3A per contact.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 20 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.475\" (12.07mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.255\" (6.48mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The post length is 0.120" (3.05mm) — enough for a standard 0.062" board with some through-hole solder fillet.
The UL94 V-0 housing means this header can be used inside equipment enclosures where flame retardance is required.
