68498-411HLF — Amphenol product photo
Amphenol

68498-411HLF BERGSTIK® II Header, 11 Pos, 0.100" Pitch, 5 A

MPN68498-411HLF
Active

Amphenol BERGSTIK® II unshrouded header, 68498-411HLF, 11 positions, 1 row, 0.100" (2.54 mm) pitch, 5 A, 110 V, right-angle through-hole, tin-plated contacts, UL94 V-0.

$0.6800Ref. price · indicative, final on quote
68498-411HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68498-411HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.095\" (2.41mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions11
Contact finish - postTin
Contact length - post0.220\" (5.58mm)
Contact finish - matingTin
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

It uses a 0.100" (2.54 mm) pitch and carries a 5 A per-contact current rating at 110 V. The housing is black, rated UL94 V-0, and uses a push-pull fastening style with no locking latch.

Position count and footprint match

The 11 positions of the 68498-411HLF sit between the 10-position 68422-410HLF and the 12-position 68015-412HLF in the same BERGSTIK® II right-angle, single-row family. All three share the 0.100" pitch, 5 A rating (68422-410HLF) or 3 A rating (68015-412HLF, 68016-406HLF), and identical 100.0 µin tin plating.

Frequently asked questions

What are the exact specifications of 68498-411HLF?

The 68498-411HLF is an 11-position, single-row, unshrouded header with 0.100" (2.54 mm) pitch, rated 5 A per contact at 110 V. It uses right-angle through-hole mounting, tin-plated phosphor bronze contacts (100.0 µin on mating surface), and a UL94 V-0 black housing.

What is the equivalent part to 68498-411HLF?

The closest functional equivalent in the same BERGSTIK® II right-angle, single-row family is the 10-position 68422-410HLF (same 0.100" pitch, 5 A rating, tin plating) or the 12-position 68015-412HLF (same pitch, 3 A rating). The 68498-411HLF has no official cross-reference or second-source listed.

Is 68498-411HLF RoHS compliant?

Yes, the 68498-411HLF is RoHS compliant per the manufacturer.
