68604-219HLF — Amphenol product photo
Amphenol

68604-219HLF Amphenol ICC BERGSTIK II Header, 19 Pos 2.54mm

MPN68604-219HLF
Active

Amphenol ICC (FCI) BERGSTIK® II header, order code 68604-219HLF, 19 positions, single row, 0.100" (2.54mm) pitch, 3 A, unshrouded, through-hole, solder termination, gold or GXT™ mating contacts.

$1.7491Ref. price · indicative, final on quote
68604-219HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68604-219HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions19
Contact length - post0.120\" (3.05mm)
Overall contact length0.600\" (15.24mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.380\" (9.65mm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

BERGSTIK II unshrouded header, 19 circuits

The 68604-219HLF is the 19-circuit member of the Amphenol ICC (FCI) BERGSTIK® II unshrouded header line. Rated 3 A per contact with gold or GXT™ mating finish at 15.0µin (0.38µm) thickness, the single-row header operates from -65°C to 125°C and carries UL94 V-0 black insulation.

Single-row selection at 0.100" pitch

The 19-position 68604-219HLF sits at the 0.100" (2.54mm) pitch common to the BERGSTIK II series. The unshrouded through-hole footprint and push-pull fastening are shared across the line — the position count is the sole selection variable for matching circuit count on the board.

Frequently asked questions

What compliance documentation does Amphenol ICC (FCI) provide for 68604-219HLF?

The header carries UL94 V-0 flammability rating. RoHS and REACH compliance documentation is available from the manufacturer upon request.
