Amphenol ICC (FCI) BERGSTIK® II, 68693-408HLF, unshrouded dual-row header, 8 positions, 0.100" (2.54 mm) pitch, through-hole solder termination, tin-plated contacts, 3 A rating.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.520\" (13.21mm) |
| Overall contact length | 0.938\" (23.83mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 68693-408HLF: All 8 positions are loaded, so the pinout is a simple 2x4 grid.
The wide temperature floor suits equipment that sees cold soak or thermal cycling.
That is a thick tin layer — good for moderate mating cycles (50-100 cycles typical for tin) in a low-vibration environment.
All positions are loaded.
Yes.
