68695-154HLF — Amphenol product photo
Amphenol

Amphenol FCI 68695-154HLF BergStik II Header, 54 Pos

MPN68695-154HLF
Active

Amphenol FCI BergStik II 68695-154HLF, 54-position dual-row unshrouded header, 0.100" (2.54 mm) pitch, right-angle through-hole mount, gold or Gold GXT contact plating 30.0 µin, rated 5 A per circuit at 110 V, UL94 V-0 housing.

$2.3149Ref. price · indicative, final on quote
68695-154HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68695-154HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions54
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.090\" (2.29mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

The Amphenol FCI 68695-154HLF is a 54-position dual-row unshrouded header from the BergStik II series, on the standard 0.100" (2.54 mm) pitch that defines the board-level footprint for this class of board-to-board interconnect.

Push-pull fastening means no secondary locking hardware; retention relies on the contact normal force and the unshrouded pin geometry.

Plating and duty cycle

That thickness is well into the industrial-grade range — suited for repeated mating cycles and environments where bare tin would fret or corrode. The phosphor bronze base metal adds spring retention and resists stress relaxation over temperature swings. For a 54-position header that may see field-service reconnections, the plating grade is the reliability differentiator.

Frequently asked questions

What is the pitch of 68695-154HLF?

The mating pitch is 0.100" (2.54 mm), with the same 0.100" row spacing — a standard footprint for BergStik headers.

Is 68695-154HLF unshrouded?

Yes, the 68695-154HLF is an unshrouded header — the pins are exposed with no plastic shroud, which means the mating receptacle provides the polarization and keying.
