68697-114HLF — Amphenol product photo
Amphenol

68697-114HLF BERGSTIK II Header, 14-Pos, 0.100" Pitch, 5A

MPN68697-114HLF
Active

Amphenol FCI BERGSTIK® II, Header, 14 Positions, 2 Rows, 0.100" (2.54mm) Pitch, Through Hole, Right Angle, Solder, 5A, 110V, Gold or Gold GXT™ (30µin), UL94 V-0, Black.

$0.6255Ref. price · indicative, final on quote
68697-114HLF datasheet
StockContact for availability
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68697-114HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole, Right Angle
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.190\" (4.83mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBag
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows2
Pitch0.100\" (2.54mm)
Positions14
Row spacing - mating0.100\" (2.54mm)
Contact length - post0.125\" (3.18mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.230\" (5.84mm)
Contact finish thickness - mating30.0µin (0.76µm)

Product details

Rated 5A per circuit at 110V, with 30.0µin gold or Gold GXT™ plating on the mating contacts — the 30µin thickness supports repeated mating cycles in controlled environments without the cost of heavy-duty gold.

Within the BERGSTIK® II family, the 68697-114HLF carries 14 positions at 0.100" pitch. Both share the 5A rating and right-angle orientation.

The UL94 V-0 rated black thermoplastic housing and RoHS-compliant construction meet the material compliance requirements for equipment sold into EU and North American markets.

Frequently asked questions

What is the pinout of 68697-114HLF?

The header has 14 positions loaded in two rows at 0.100" pitch, with a 0.230" mating pin length and a 0.125" solder post. The pinout follows standard BERGSTIK® II dual-row numbering — row A on one side, row B on the other — but the exact signal assignment depends on your PCB layout.
