Amphenol ICC (FCI) BERGSTIK® II header, order code 68739-438HLF, 38 positions, dual row, 0.100" (2.54mm) pitch, 3 A, tin-plated mating contacts, through-hole, solder termination.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Gender | Male Pin |
| Mounting type | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 38 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.156\" (3.96mm) |
| Overall contact length | 0.486\" (12.34mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
The 68739-438HLF is the 38-circuit member of Amphenol ICC (FCI)'s BERGSTIK II unshrouded header line, a dual-row through-hole board-to-board interconnect.
The 38 positions are loaded across two rows spaced 0.100" (2.54 mm) apart, matching the standard BERGSTIK II footprint.
The 68739-438HLF is listed with a Board to Board style, designed for mating with a compatible receptacle on a parallel PCB.
RoHS and REACH compliance documentation is available from Amphenol ICC (FCI) upon request.
