Amphenol 68743-472HLF BERGSTIK II Header 72-Pos 2.54mm Pitch
MPN68743-472HLF
Obsolete
Amphenol BERGSTIK II 68743-472HLF dual-row unshrouded header, 72 positions, 0.100" (2.54mm) pitch, tin-plated square pin contacts, 2-row, push-pull fastening, through-hole termination, UL94 V-0, 0.100" insulation height.
$8.0352Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.220\" (5.58mm) |
| Overall contact length | 0.638\" (16.21mm) |
| Contact finish - mating | Tin |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 100.0µin (2.54µm) |
Frequently asked questions
What replaces the 68743-472HLF if it is obsolete?
No official successor order code is listed for this variant. A pin-compatible variant in the same BERGSTIK II series — same 72-position, 0.100" pitch dual-row footprint and tin-plated contacts — should be confirmed directly with the manufacturer or distributor.
