68771-436HLF — Amphenol product photo
Amphenol

68771-436HLF Amphenol ICC BERGSTIK II Header, 36 Pos 2.54mm

MPN68771-436HLF
Active

Amphenol ICC (FCI) BERGSTIK® II header, order code 68771-436HLF, 36 positions, single row, 0.100" (2.54mm) pitch, 3 A, tin-plated mating contacts, through-hole, solder termination.

$1.4414Ref. price · indicative, final on quote
68771-436HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68771-436HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Current rating3A
Operating temperature-65°C~125°C
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions36
Contact finish - postTin
Contact length - post0.100\" (2.54mm)
Overall contact length0.470\" (11.94mm)
Contact finish - matingTin
Contact length - mating0.270\" (6.86mm)
Contact finish thickness - mating100.0µin (2.54µm)

Product details

BERGSTIK II 36-position unshrouded header

The 68771-436HLF is the 36-position member of Amphenol ICC's BERGSTIK® II unshrouded header line, built for board-to-board stacking with a push-pull fastening interface. Tin-plated mating contacts rated 3 A per position at 0.100" (2.54mm) pitch; the through-hole solder termination and UL94 V-0 black insulation suit standard PCB assembly flows.

Active production status

Active lifecycle — Amphenol ICC (FCI) continues production of the 68771-436HLF under the BERGSTIK® II series.

Frequently asked questions

What compliance documentation is available for the 68771-436HLF?

The header carries a UL94 V-0 material flammability rating. RoHS and REACH documentation is provided by Amphenol ICC (FCI) per standard datasheet and compliance declarations.
