Amphenol ICC (FCI) BergStik® II unshrouded header, 72 positions, dual-row, 0.100" (2.54 mm) pitch, through-hole solder termination, male square pins, 3 A per contact, 30 µinch gold plating, UL94 V-0 black housing, bulk package.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 72 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.318\" (8.08mm) |
| Overall contact length | 0.736\" (18.69mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.318\" (8.08mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
No official successor or pin-compatible alternative is listed from Amphenol ICC. The BergStik II series includes many 0.100" pitch headers; a different position count or plating grade would be a functional replacement only if the board layout is adjusted.
It is unshrouded — the pins are exposed without a plastic shroud. This means the mating connector must be aligned manually or by the board layout; there is no polarization keying.
No official pin-compatible alternative is listed from Amphenol ICC. Within the BergStik II series, a different position count or plating grade (e.g., tin instead of gold) would require a board layout change. For a direct drop-in, the exact 68779-172HLF is the only verified match.
