68797-236HLF — Amphenol product photo
Amphenol

Amphenol BERGSTIK® II 68797-236HLF, 36 Pos Header, 2.54mm

MPN68797-236HLF
Active

Amphenol BERGSTIK® II 68797-236HLF, unshrouded male pin header, 36 positions, 1 row, 0.100" (2.54mm) pitch, through hole, solder termination, 5A, 110V, gold 15.0µin plating.

$2.4900Ref. price · indicative, final on quote
68797-236HLF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

68797-236HLF Technical Specifications
ParameterValue
SeriesBERGSTIK® II
GenderMale Pin
Mounting typeThrough Hole
Connector typeHeader
Fastening typePush-Pull
Voltage rating110V
Current rating5A
Contact materialPhosphor Bronze
Insulation colorBlack
Insulation height0.100\" (2.54mm)
Material flammability ratingUL94 V-0
StyleBoard to Board
PackageBulk
ShroudingUnshrouded
TerminationSolder
Contact shapeSquare
Rows1
Pitch0.100\" (2.54mm)
Positions36
Contact length - post0.213\" (5.40mm)
Overall contact length0.413\" (10.49mm)
Contact finish - matingGold or Gold, GXT™
Contact length - mating0.100\" (2.54mm)
Contact finish thickness - mating15.0µin (0.38µm)

Product details

The Amphenol 68797-236HLF is a 36-position unshrouded male pin header from the BERGSTIK® II series, designed for board-to-board interconnects on a standard 0.100" (2.54mm) pitch.

Against the 68001-236HLF, which shares the same 36-position count and 0.100" pitch but is rated 3 A per contact, the 68797-236HLF carries a higher 5 A rating — the difference matters when the board layout demands more current per line without increasing the footprint.

The 0.100" (2.54mm) insulation height and 0.213" (5.40mm) post length fit common PCB thicknesses and mating connector profiles.

Frequently asked questions

Is the 68797-236HLF RoHS compliant?

Yes, the 68797-236HLF is RoHS Compliant.

What is the 68797-236HLF's listed style and series?

The 68797-236HLF is a Board to Board connector in the BERGSTIK® II series.
