Amphenol ICC (FCI) BergStik II header, order code 68799-160HLF, 60 positions, dual row, 0.100" (2.54 mm) pitch, unshrouded, through-hole, solder termination, male pin, square contact, UL94 V-0.
68799-160HLF Amphenol ICC (FCI) BergStik II Header, 60 Pos
MPN68799-160HLF
Obsolete
Amphenol ICC (FCI) BergStik II header, order code 68799-160HLF, 60 positions, dual row, 0.100" (2.54 mm) pitch, unshrouded, through-hole, solder termination, male pin, square contact, UL94 V-0.
$6.7035Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent supplier — new & surplus connector stock· Listing updated Jul 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Package | Bulk |
| Shrouding | Unshrouded |
All specifications
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 60 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.595\" (15.11mm) |
| Overall contact length | 0.925\" (23.50mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
What compliance documentation is available for 68799-160HLF?
RoHS and REACH status are not confirmed in the available data; request documentation at RFQ.
