Amphenol ICC (FCI) BERGSTIK® II unshrouded header, 28 positions, 0.100" (2.54 mm) pitch, through-hole solder termination, male square pins with 30 µinch gold or GXT™ mating finish, rated 3 A per contact, UL94 V-0 black housing.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bulk |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 28 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.285\" (7.24mm) |
| Overall contact length | 0.615\" (15.62mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 69133-128HLF: All 28 positions are loaded, so the BOM position count matches the pin count directly.
The mating finish is 30 µinch gold or GXT™ over nickel — this is a 500-cycle minimum interface. The gold layer also resists corrosion in humid or mildly aggressive environments.
This is an unshrouded header with push-pull fastening — no locking latch.
No.
