69146-206LF — Amphenol product photo
Amphenol

69146-206LF Amphenol ICC (FCI) Mini-Jump 6-Position Open

MPN69146-206LF
Active

Amphenol ICC (FCI) Mini-Jump™, 69146-206LF, open-top female socket shunt, 6 positions (1 x 6), 0.100" (2.54 mm) pitch, 0.200" (5.08 mm) height, 2 A rating, 30.0 µin (0.76 µm) gold or GXT contact finish, UL94 V-0 polyester housing, black.

$1.2700Ref. price · indicative, final on quote
69146-206LF datasheet
StockContact for availability
Lead timeIn Stock wk
MOQ1 pcs
  • New & original stockTraceable channels only — no mixed lots, no re-taped reels.
  • Factory packaging where availableSealed reels, trays and bags; cut quantities always stated on the quote.
  • Photo-verified countsEvery line counted and photographed before the box closes.
  • PayPal buyer protectionPay by T/T, PayPal or Payoneer — card payments covered end to end.
How we verify every order →

Specifications

69146-206LF Technical Specifications
ParameterValue
TypeOpen Top
SeriesMini-Jump™
Current rating2A
ColorBlack
Height0.200\" (5.08mm)
Housing materialPolyester Thermoplastic
Material flammability ratingUL94 V-0
Pitch0.100\" (2.54mm)
GenderFemale Sockets
PackageBulk
Contact finishGold or Gold, GXT™
Contact finish thickness30.0µin (0.76µm)
Number of positions or pins6 (1 x 6)

Product details

6-Position Open-Top Shunt for 0.025" Square Pins

The 69146-206LF: The open-top profile exposes the contact beams for probing or visual inspection after installation. The UL94 V-0 polyester thermoplastic housing withstands wave-solder and reflow temperatures, and the 0.200" (5.08 mm) profile keeps the shunt low enough to fit under shrouded headers or in tight board-to-board clearance.

Position Count and Current Rating vs. Siblings

Compared to the 4-position 69146-204LF (same single-row layout, same 2 A rating), the 69146-206LF adds two positions for wider configuration options on a 1 x 6 header. Both share the 0.100" pitch, 0.200" height, and 30 µinch gold/GXT finish. The dual-row 69145-206LF (6 positions, 2 x 3) carries a 3 A rating — one amp higher per contact — but uses a different footprint and occupies more board area.
