Amphenol ICC (FCI) BERGSTIK® II, 69157-216HLF, unshrouded dual-row header, 16 circuits, 0.100" (2.54 mm) pitch, through-hole solder termination, 3 A, 15.0 µinch gold-plated mating contacts.
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
| Parameter | Value |
|---|---|
| Package | Bag |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 16 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.110\" (2.79mm) |
| Overall contact length | 0.410\" (10.41mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.200\" (5.08mm) |
| Contact finish thickness - mating | 15.0µin (0.38µm) |
The 69157-216HLF: The gold layer resists oxidation that would increase contact resistance over time.
The base product number 69157 covers multiple position counts and plating options in the BERGSTIK II family — confirm the 16-position, gold-plating variant matches the BOM line.
The pitch is 0.100" (2.54 mm) on both the mating interface and the row spacing, matching standard 0.100" headers and receptacles.
Within the BERGSTIK II series, the 69157-216HLF is a 16-position, gold-plated variant. A tin-plated version (same pitch and position count) would be a cost-reduction alternative if the application does not require the 15.0 µinch gold mating surface.
