Amphenol ICC (FCI) Mini-PV™, Basics+ series, 69167-115HLF, 15-position single-row shrouded header, 0.100" (2.54 mm) pitch, through-hole solder termination, friction lock, 30 µin gold-plated mating contacts.
| Parameter | Value |
|---|---|
| Series | Mini-PV™, Basics+ |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Friction Lock |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.386\" (9.80mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Bulk |
| Shrouding | Shrouded - 2 Wall |
| Parameter | Value |
|---|---|
| Termination | Solder |
| Contact shape | Square |
| Rows | 1 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 15 |
| Contact length - post | 0.120\" (3.05mm) |
| Overall contact length | 0.465\" (11.81mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
It is RoHS compliant. Sourced through independent distribution channels against your BOM quantity.
The 0.386" (9.80 mm) insulation height sets the z-height budget above the PCB for mating receptacle clearance.
Yes – it is a shrouded-2-wall header with a friction lock fastening system, designed to mate with standard 0.100" pitch crimp-socket receptacles for wire-to-board applications.
The 12-position 69167-112HLF is the closest sibling – same pitch, plating, lock, and termination. If the BOM allows fewer circuits, it is a direct drop-in replacement without board layout changes.
