Board Layout Fit: 0.100" Pitch, 10-Pin Dual-Row
The 71276-110HVLF: Surface-mount termination with pick-and-place features means it runs through a standard SMT line without a secondary hand-solder step.
71276-110HVLF BERGSTIK® II Header, 10-Pin, 0.100" Pitch, SMT
MPN71276-110HVLF
Active
Amphenol ICC (FCI) BERGSTIK® II, 71276-110HVLF, Board to Board, Header, Male Pin, 10 Positions, 0.100" (2.54mm) Pitch, Surface Mount, Solder, Unshrouded, Gold Mating Finish, UL94 V-0
$1.0400Ref. price · indicative, final on quote
Source DocumentedChannel stated on listing & quote
Condition PhotosReal unit photos / video on request
WhatsApp AnswersFast human replies for stock & sourcing questions
Worldwide DispatchDHL/FedEx — transit quoted per order
Independent China distributor & sourcing agent· Listing updated Aug 2026
Specifications
| Parameter | Value |
|---|---|
| Series | BERGSTIK® II |
| Type | Male Pin |
| Mounting | Surface Mount |
| Connector type | Header |
| Fastening type | Push-Pull |
| Current rating | 3A |
| Operating temperature | -65°C~130°C |
| Contact material | Phosphor Bronze |
| Insulation color | Black |
| Insulation height | 0.100\" (2.54mm) |
| Material flammability rating | UL94 V-0 |
| Style | Board to Board |
All specifications
| Parameter | Value |
|---|---|
| Package | Tape & Reel (TR) |
| Features | Pick and Place |
| Shrouding | Unshrouded |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 10 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact finish - mating | Gold |
| Contact length - mating | 0.230\" (5.84mm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
Product details
Frequently asked questions
Is 71276-110HVLF RoHS compliant?
RoHS compliance is standard for the BERGSTIK® II series; confirm with the RoHS certificate available on the product drawing.
