Amphenol ICC (FCI) Quickie™ series, 71918-106LF, 6-position dual-row shrouded header, 0.100" (2.54mm) pitch, through-hole solder termination, gold GXT™ plated male pins, latch lock/eject hooks, RoHS compliant, active production.
| Parameter | Value |
|---|---|
| Series | Quickie™ |
| Type | Male Pin |
| Mounting | Through Hole |
| Connector type | Header |
| Fastening type | Latch Lock/Eject Hooks |
| Contact material | Phosphor Bronze |
| Insulation color | Gray |
| Insulation height | 0.685\" (17.40mm) |
| Insulation material | Thermoplastic, Glass Filled |
| Material flammability rating | UL94 V-0 |
| Style | Board to Cable/Wire |
| Package | Tube |
| Parameter | Value |
|---|---|
| Features | Keying Slot, Mounting Flange |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 6 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact finish - post | Tin |
| Contact length - post | 0.114\" (2.90mm) |
| Contact finish - mating | Gold, GXT™ |
| Contact length - mating | 0.228\" (5.80mm) |
| Contact finish thickness - post | 78.7µin (2.00µm) |
| Contact finish thickness - mating | 30.0µin (0.76µm) |
The 71918-106LF: Tube packaging per the standard factory pack.
This header mates with Quickie™ series IDC sockets and discrete-wire receptacles that accept the 0.100" pitch dual-row layout. The 0.228" (5.80mm) mating pin length provides sufficient wipe for reliable contact with standard female crimp or IDC terminals. The keying slot and mounting flange prevent mis-mating and add mechanical stability to the board interface.
Yes, it is RoHS compliant per the manufacturer's listing.
