Amphenol ICC (FCI) LATCH-N-LOK™ header, 8 circuits, 2-row, 0.100" (2.54mm) pitch, right-angle through-hole, shrouded 4-wall, with gold or GXT™ contact finish, shielded, rated 2.5 A per contact at 250 VDC.
| Parameter | Value |
|---|---|
| Series | LATCH-N-LOK™ |
| Type | Male Pin |
| Mounting | Through Hole, Right Angle |
| Connector type | Header |
| Fastening type | Latch Holder |
| Voltage rating | 250VDC |
| Current rating | 2.5A |
| Contact material | Copper Alloy |
| Insulation color | Black |
| Insulation height | 0.715\" (18.16mm) |
| Insulation material | Thermoplastic |
| Material flammability rating | UL94 V-0 |
| Parameter | Value |
|---|---|
| Style | Board to Cable/Wire |
| Package | Bulk |
| Features | Board Guide, Ground Pin, Shielded |
| Shrouding | Shrouded - 4 Wall |
| Termination | Solder |
| Contact shape | Square |
| Rows | 2 |
| Pitch | 0.100\" (2.54mm) |
| Positions | 8 |
| Row spacing - mating | 0.100\" (2.54mm) |
| Contact length - post | 0.130\" (3.30mm) |
| Contact finish - mating | Gold or Gold, GXT™ |
Integrated board guide, ground pin, and shielding add mechanical alignment and EMI containment, which is useful in industrial or telecom environments where noise coupling is a concern.
The insulation height of 0.715" (18.16mm) gives clearance for the mating receptacle and cable strain relief.
It is available in bulk packaging.
The 74355-1042LF is the closest second-source — same 8 positions, 2 rows, 0.100" pitch, gold/GXT™ finish, and right-angle through-hole mounting. The only difference is packaging: 1041LF is bulk, 1042LF is tray. For a 12-position option with thicker 30.0 µinch gold, see the 78098-104LF.
