The Amphenol 75160-102-11LF is an 11-position unshrouded male pin header from the BERGSTIK series, designed for board-to-board stacking applications. It carries a 0.100" (2.54 mm) pitch on a single row, with all positions loaded. The through-hole solder tails measure 0.135" (3.43 mm) long, and the mating pin length is 0.230" (5.84 mm) — a standard profile that fits most BERGSTIK receptacles without bottoming out.
Key ratings and what they mean
Rated 5 A per circuit at 110 V — this is signal-level current, not a power rail. The 30.0 µin (0.76 µm) gold GXT plating on the mating surface gives it a solid cycle life for repeated mating; the phosphor bronze contact material handles flex without taking a set. The UL94 V-0 thermoplastic housing means it's flame-rated for equipment inside an enclosure. Operating temperature spans -65°C to 130°C — wide enough for industrial cabinets and outdoor telecom gear. The push-pull fastening type means no locking latch, so in high-vibration environments you'll want to secure the mated pair with a wire tie or potting.
Mating and footprint fit
This unshrouded header mates with any standard BERGSTIK receptacle or IDC socket at the same 0.100" pitch — no keying, no shroud to block a misaligned mate. The 0.100" (2.54 mm) insulation height keeps the mated stack low. On the board side, the through-hole tails need 0.135" of plated-through-hole depth; the 0.100" row spacing is a standard drill pattern.
