The Amphenol BERGSTIK 75160-115-36LF is a 36-position, single-row unshrouded male pin header on the standard 0.100" (2.54mm) pitch. The header carries 30.0µin gold GXT plating on the mating surface, rated for 5A per contact, and the housing is molded from UL94 V-0 thermoplastic.
The 0.100" (2.54mm) pitch is the de facto standard for breadboard-compatible layouts and legacy through-hole designs — any board with a 0.100" grid will accept this header without footprint changes. The 36 positions must match your circuit count exactly; this is a fully loaded header with all positions populated. 5A per-contact rating. 30.0µin gold GXT plating on mating surface.
The male pin dimensions are 0.335" (8.51mm) mating length and 0.100" (2.54mm) post length, with an overall contact length of 0.535" (13.59mm). Termination is through-hole solder — the 0.100" (2.54mm) post length is designed for standard 0.062" (1.6mm) thick PCBs.
Compliance and Operating Range
The header is rated for 110V maximum working voltage.
